EVA Film For Vacuum Casting (V-process)
Precision-engineered for V-Process Vacuum Casting, Aristo Flexi Pack's EVA Film delivers exceptional performance and reliability. Manufactured on our state-of-the-art German Reifenhäuser auto-gauge blown film line, the film offers outstanding thermoformability and elongation, making it ideal for use with complex, contoured, or sharp-edged molds.
With superior adaptability to mold shapes, our EVA film minimizes casting defects and material waste — leading to higher efficiency and lower production costs.
Backed by years of R&D and a dedicated production team, Aristo has pioneered the development of ultra-thin EVA film, engineered for high raw material utilization and reduced casting failures. This innovation has enabled us to replace costly imported alternatives and supply high-performance films to customers across India, Southeast Asia, the Americas, Eastern Europe, and beyond.
Whether you're looking to enhance casting precision, optimize input costs, or reduce rejection rates, Aristo's EVA Film sets a new benchmark in the vacuum casting space.
Benefits
Excellent Thermoformability
Specifically designed for V-Process Vacuum Casting, our EVA film adapts seamlessly to shaped and sharp-edged molds.
High Tensile Strength
Delivers consistent performance with tensile strength of ≥ 20 MPa in both TD (Transverse Direction) and MD (Machine Direction).
Superior Elongation Properties
Exceptional stretchability with elongation rates of ≥ 600%, ensuring reliable molding performance without tearing or deformation.
Low Shrinkage Rate
Maintains dimensional accuracy during casting with ≤ 4.5% shrinkage, reducing the risk of warping or surface defects.
Versatile Thickness Range
Available from Very Thin (≤ 100µ) to Very Thick (≥ 300µ) options, suitable for fine to extremely large casting applications.
Customisable Dimensions
Supplied in widths up to 2200 mm (single layer) and 4400 mm (double layer), offering flexibility for different machine setups and project scales.
Advanced German Manufacturing Line
Produced on a Reifenhäuser auto-gauge blown film line for precise gauge control and uniform quality.
Global Quality Standard
Successfully replacing imported films across India and exported to Southeast Asia, the Americas, Eastern Europe, and other markets.
Efficient & Eco-Conscious
Our ultra-thin variant helps lower raw material consumption, cut costs, and reduce environmental impact—without compromising quality.
Technical Specifications
|
|
|
Single Layer Width (mm) |
Double Layer Width (mm) |
|
|
|
|
|
Very Thin |
≤ 100 |
≤ 2200 |
≤ 4400 |
≥ 20 (TD & MD) |
≥ 600 (TD & MD) |
≤ 4.5 |
Fine surface plate castings (e.g. locomotives) |
|
Thin |
100–200 |
Medium-size castings (e.g. pump body, pot piece, bathtub) |
|||||
|
Thick |
200–300 |
Large castings with complex shapes (e.g. counterweights, reduction housings) |
|||||
|
Very Thick |
≥ 300 |
Very large castings (e.g. machine beds, marine equipment) |
Grade
Micron (μm)
